AC Supply


  • Standard Analogue phone,SIP Phone,GSM/3G Phone
  • Corrosion Resistant & Anti vandal body
  • Stable, durable and violence-resistible with a waterproof ratio of IP 66-IP67
  • Built in Ringer, which provides penetrating calling signal
  • Tamper resistant fixings,Fast-fit terminal connection
  • Weatherproof and corrosion resistant handset
  • With a built-in speaker and a microphone,available for making hands-free calls
  • Compatible with standard SIP protocol, independently accessible to VOIP phone system.
  • Advanced digital echo cancellation technology, fully eliminate echo and prevent squeal
  • It adopts high strength stainless steel shell and hexagon socket screw,with tamper-resistant
  • Can be programmed remotely by tone phone or locally via keypad or by send message
Frequency Band Quad-Band:GSM/GPRS/EDGE 850/900/1800/1900MHz
Dual-Band: UMTS/HSDPA 900/2100MHz
Transmitting Power Class 4(2 Watt) at GMS 850MHz and 900MHz
Class (1 Watt) at DCS 1800MHz and PCS 1900MHz
LED Indicators GSM Status Display
Speaker Output 9 adjustable volume levels
Microphone Input 9 adjustable volume levels
Adjust the volume automatically The environment and SMS Control
Relay Output 1 relay output (Normal-close) for door lock
Power Supply Input voltage AC 6V to 16V
Power Consumption Standby: < 12V / 30mA
Working < 12V / 200mA
Operating Temperature -35°C ~ +80°C
Remote Programming Support SMS Programming
CPU Board Module 100,000 hr (12yr) (min)
Certificate CE
Protection Rating IP65-IP66


Let our helpful sales team assist in matching your project requirements to the features of our IP communication systems.
